This machine is built in China for quarries, mineral processing plants and aggregate producers, and is supplied for wholesale and OEM orders. The table below lists the build, the working parameters and the packing published for the unit.

Specifications

Rated effective volume	5m ³
Maximum driving speed in gear I	5.5 km/h
Second gear	10 km/h
Grade III	18 km/h
Grade IV	28 km/h
Maximum climbing ability (heavy load)	25%
Maximum traction force	100 kN
Turning radius	inner side 3750 mm
Steering angle	± 42 °
Minimum ground clearance	280 mm
Feed height	2450 mm
Discharge height	1000-1270 mm
Dimensions (length x width x height)	9200 mm x 2000mm x 2450mm (± 100)
Operating weight of the whole machine	14t
Engine	German Made Deutz TCD4.1 water-cooled low pollution engin
Rated power/rated speed	115kW/2300 r/min
Starting method	Electric start
Exhaust gas purification method	Catalytic purification method
Throttle control	Electronic throttle controller
Transmission model	USA DANA R36420
Torque converter model	USA DANA C273
Drive axle model	Domestic Top Brand A50
Maximum pressure of braking system	16 MPa
Service brake	Wet multi disc brake
Parking brake	Spring brake, hydraulic release
Type	Central articulated, hydraulic steering
Maximum pressure of steering system	14 MPa
Working pump	Variable displacement piston pump
Working valve	Variable displacement piston motor
Maximum working system pressure	16MPa
System voltage	24V DC
Starting motor voltage/power	24V/6kW
Lighting	2 front headlights, 2 × 75W, 24V
Hydraulic oil tank	200 L
Fuel tank	200 L

Material & Construction

The grade iii is stated as 18 km/h. That choice of wear material sets the service life of the working surfaces and, together with the casting weight, most of the unit price. It is the figure buyers confirm against a wear-life figure or a reference installation before ordering.

Capacity & Drive

Rated performance is given as maximum driving speed in gear i rated at 5.5 km/h. Nameplate capacity assumes a defined feed size and bulk density. Ask for the curve rather than the single number if the plant has to hold a product-size specification.

Dimensions & Packing

Dimensions and shipping data are stated as rated effective volume of 5m ³. For heavy units the packing format is part of the quote: skid, crate or container loading changes both the freight cost and the unloading equipment required on site.

Customisation & OEM Service

The unit can be built to your duty: alternative wear material, a different motor voltage or drive arrangement, and a modified discharge setting can all be quoted against your specification. Send the feed material, target output and site power supply and the factory will confirm what is feasible on this frame size. For this item, minimum order quantity is 1 Piece and the reference price starts at US$120,000.00-150,000.00 per set.

Ordering & Samples

Ordering starts with the duty specification and a layout drawing, followed by a proforma against the confirmed configuration. Delivery schedules are quoted per order rather than published on the page.
