This drilling rig is offered for bulk supply and OEM production. Working principle, rated capacity and configuration are set out in the table below, with the ordering details further down the page.

Specifications

Maximum torque (kN.m)	15
Speed (r/min)	33/53/77/106
Maximum hole diameter(mm)	520
Maximum lifting force of main winch (KN)	50
Lifting speed (m/s)	1/1.67/3.3
Rated pressure of hydraulic system (MPa)	16
Active drill pipe (mm)	10810810500
Drill tower height (m)	15
Rated load of rig (t)	10
Mud Pump Model	TBW-850/5A
electric motor	55
Electric Slurry Pump	90
diesel engine	6135AZN-1-SM
Diesel Slurry Pump	154KW
Dimensions (m)	152.54
working state size	114.518.5
Machine weight (t)	19

Capacity & Drive

Rated performance is given as speed (r/min) rated at 33/53/77/106. Those figures are quoted against a stated feed material and moisture content, so a site with harder rock or a wetter feed should expect a lower effective throughput than the nominal number.

Dimensions & Packing

Dimensions and shipping data are stated as maximum hole diameter(mm) of 520. Overall dimensions and unit weight decide the transport class, the lifting points and whether the machine ships as a whole unit or in modules for site assembly — worth fixing before freight is quoted.

Customisation & OEM Service

The unit can be built to your duty: alternative wear material, a different motor voltage or drive arrangement, and a modified discharge setting can all be quoted against your specification. Send the feed material, target output and site power supply and the factory will confirm what is feasible on this frame size. For this item, minimum order quantity is 1 Piece and the reference price starts at US$20,000.00 per set.

Ordering & Samples

Ordering starts with the duty specification and a layout drawing, followed by a proforma against the confirmed configuration. Delivery schedules are quoted per order rather than published on the page.
