This drilling rig is offered for bulk supply and OEM production. Working principle, rated capacity and configuration are set out in the table below, with the ordering details further down the page.
Specifications
| 1 | Basic parameters |
| 2 | Equipment configuration |
| System pressure (bar) | 200 |
| Impact power (kW) | 20 |
| Impact energy (Hz) | 380 |
| Maximum rotation torque (N·m) | 820 |
| Rotation speed (r/min) | 220 |
| Water consumption (L/min) | 30-50 |
| Drilling diameter (mm) | φ45-φ115 |
| Coverage area ( ) | 24 |
| Coverage width/height (mm) | 5025/5000 |
| Boom lifting angle | -43° ~ +52° |
| Boom swing angle | ±30° |
| Maximum propulsion force (kN) | 15 |
| Drill rod length (mm) | 3090 (standard)/3700 |
| Drilling depth per push (mm) | 2830 (standard)/3440 |
| Flip angle | ±180° |
| Pitch angle | -3°~ +90° |
| Power (kW) | 55.8 |
| Maximum torque | 310Nm/1600rpm |
| Emission and noise standards | National IV (EURO IV) |
| Transmission system | Four-wheel drive |
| Travel speed (km/h) | 0~15 |
| Ground clearance (mm) | 220 |
| Steering system | Articulated steering |
| Steering angle (°) | ±40 |
| Wheelbase (mm) | 2300 |
| Motor power (kW) | 55 |
| Hydraulic oil tank capacity (L) | 180 |
| Rated displacement (L/min) | 52 (12bar) |
| Water outlet pressure (bar) | 12 |
| Minimum water inlet pressure (bar) | 2 |
| Voltage (V)/frequency (Hz) | 380/50 |
| Starting method | Star delta |
| Safety protection system function | Leakage protection, overload protection, short circuit protection |
Capacity & Drive
Rated performance is given as hydraulic oil tank capacity (l) of 180 and impact power (kw) rated at 20. Throughput is normally quoted for a reference feed gradation. Hardness, moisture and the target product size all move the real figure, which is why the duty cycle is worth stating up front.
Dimensions & Packing
Dimensions and shipping data are stated as drilling diameter (mm) of φ45-φ115. Shipping weight and footprint drive container or flat-rack loading and the crane capacity needed at the destination, so both are normally confirmed together with the packing list.
Customisation & OEM Service
OEM production covers the nameplate, the paint scheme and the electrical configuration, plus frame modifications within the limits of the existing pattern. A drawing review normally comes back with the quotation. For this item, minimum order quantity is 1 Piece and the reference price starts at US$67,500.00-125,000.00 per set.
Ordering & Samples
Ordering starts with the duty specification and a layout drawing, followed by a proforma against the confirmed configuration. Delivery schedules are quoted per order rather than published on the page.
Product Images
Specifications on this page are those published for the item. Final parameters, configuration and lead time are confirmed on quotation.
