This drilling rig is offered for bulk supply and OEM production. Working principle, rated capacity and configuration are set out in the table below, with the ordering details further down the page.

Specifications

Hole Depth	30m
Drill Pipe Sizes	φ76×3,000mm
Hole Dia	φ110-138 mm
Hammer	4"/5"
Rotation Torque(Max.)	3,200 N. m
Rotation Speed	0-100 rpm
Working Pressure	0.7-2.5 Mpa
Length of Feed Beam	5,645 mm
Feed Travel Length	3,660 mm
Feed Extension	960mm
Feed Speed	26 m/min
Feed Force	20kN
Pull Up Force	45kN
Tramming Speed(Max.)	2.5km/h
Gradient	25°
Ground Clearance	280mm
Total Weight	5,700kg/6,000kg
Dimension	7,000×2,250×2,700mm

Product Highlights

The item is described with these characteristics:

Detailed Photos
Product Parameters
Construction Site
Related product
After Sales Service

Capacity & Drive

Rated performance is given as rotation speed rated at 0-100 rpm. Throughput is normally quoted for a reference feed gradation. Hardness, moisture and the target product size all move the real figure, which is why the duty cycle is worth stating up front.

Dimensions & Packing

Dimensions and shipping data are stated as drill pipe sizes of φ76×3,000mm. Shipping weight and footprint drive container or flat-rack loading and the crane capacity needed at the destination, so both are normally confirmed together with the packing list.

Customisation & OEM Service

OEM production covers the nameplate, the paint scheme and the electrical configuration, plus frame modifications within the limits of the existing pattern. A drawing review normally comes back with the quotation. For this item, minimum order quantity is 1 Piece and the reference price starts at US$1.00 per set.

Ordering & Samples

Ordering starts with the duty specification and a layout drawing, followed by a proforma against the confirmed configuration. Delivery schedules are quoted per order rather than published on the page.
