This drilling rig is offered for bulk supply and OEM production. Working principle, rated capacity and configuration are set out in the table below, with the ordering details further down the page.
Specifications
| Main parameter | Parameter values |
| Size | 11000*2050*2800/3650mm |
| Maximum excavation height | 7200mm |
| Drilling diameter | φ43mm-φ102mm |
| Drill pipe length | 4305mm |
| Drilling depth | 3900mm |
| Drilling speed | 0.8-2m/min |
| Motor power | 55KW |
| Fuel tank capacity | 250L |
| Overall weight | 12000kg |
| Rock drilling power head model | DZ600 |
| Rotation | Positive 135 ° Reverse 225 ° |
| Swing arm | 45 ° left and right |
| Travel compensation | 1600mm |
| Main arm stroke | 1300mm |
| Sliding rail swing angle | 2 ° elevation and 90 ° elevation |
| Diesel engine power | 60kw |
| Turn | ±40 |
| Tires | 9.00-20 |
| Climbing ability | ≤15° |
| Rear axle swing angle | ±10° |
| Approach angle/departure angle | 17°/14° |
| Inside turning radius | Inner side 3.3m/outer side 6.95m |
| Walking speed | 12km/h |
| Ground clearance | 350mm |
| Air compressor flow rate | 0.55m³/min |
| Pressure | 0.3-0.6MPa |
| Air compressor motor power | 4KW |
| Water pump flow rate | 5m³/h |
| Pump motor power | 3kw |
| Battery rate | 2x12v |
| Driving lighting | 24v |
| Work lighting | 220v |
Capacity & Drive
Rated performance is given as fuel tank capacity of 250L and drilling speed rated at 0.8-2m/min. Those figures are quoted against a stated feed material and moisture content, so a site with harder rock or a wetter feed should expect a lower effective throughput than the nominal number.
Dimensions & Packing
Dimensions and shipping data are stated as size of 11000*2050*2800/3650mm. Overall dimensions and unit weight decide the transport class, the lifting points and whether the machine ships as a whole unit or in modules for site assembly — worth fixing before freight is quoted.
Customisation & OEM Service
OEM production covers the nameplate, the paint scheme and the electrical configuration, plus frame modifications within the limits of the existing pattern. A drawing review normally comes back with the quotation. For this item, minimum order quantity is 1 Piece and the reference price starts at US$100,000.00-175,000.00 per set.
Ordering & Samples
Ordering starts with the duty specification and a layout drawing, followed by a proforma against the confirmed configuration. Delivery schedules are quoted per order rather than published on the page.
Product Images
Specifications on this page are those published for the item. Final parameters, configuration and lead time are confirmed on quotation.
